FlexUSB™

Outdoor USB-Powered CPE

2X2 300 Mbps MIMO CPE/AP/Point-to-Point

The FlexUSB™ product provides the most economical high-powered MIMO CPE connectivity solution on the market today. Compatible with virtually all 802.11n access point/base station products, the FlexUSB™ offers service providers a low cost alternative to deliver seamless, up to 300 Mbps data connectivity, while not being locked into proprietary technology. The FlexUSB™ is offered in both 2.4 and 5 GHz spectrums and features 2×2 MIMO radio and antenna technology to deliver robust connectivity.

General Information

• View Full Datasheet
• Outdoor Weatherproof Enclosure
• 300Mbps 2X2 MIMO 2.4GHz or 5GHz CPE
• Two models available: FlexUSB 5 and FlexUSB 2
• FlexUSB 2 ships with a 15dBi panel antenna
• FlexUSB 5 ships with a 18dBi panel antenna
• Fully adjustable mount
• USB-powered
• Patented antenna design
• Windows, MAC and Linux drivers available
• Pair with an iFlex™ or Flex mARC™ AP to create a robust wireless ARCFlex™ Split System solution
• Ships with an outdoor 5m USB cable (will soon ship with an 8m cable)

When paired with an iFlex™ or Flex mARC™ APs you get the following benefits:

• Change your FlexUSB™’s operating mode to transform it into a Point-to-Point endpoint or high-gain AP
• One configuration UI for multiple devices/radios
• Powered by the ARC•OS Wireless Platform
• Always-on Wireless Management Network makes installation and maintenance hassle-free
• Advanced wireless configuration options: Ack timeout, RTS, WMM, STBC, etc…
• QoS and Bandwidth Limiting
• ARCMobile™ iPhone and Android Installation App

FlexUSB™ + Indoor iFlex™ AP

Coupled with the iFlex™ indoor AP, the FlexUSB™ can be powered by the included USB cable, providing an end-to-end cost-effective split system installation. Carrier signal is relayed inside the customer premise without the need for additional networking equipment.

Learn more about the SplitStation™ and iFlex™ products.

FlexUSB™ + Outdoor Flex mARC™ AP

The FlexUSB™ can be combined with a Flex mARC™ for the ultimate split system installation providing cost-effective coverage outside the premises.

Learn more about the Split mARC™ and Flex mARC™ products.

Standalone Installation

For the ultimate cost-effective CPE solution, the FlexUSB™ can be installed on the customer premises and routed directly to the customer PC or laptop via USB cable.
