Antenna Products Corporation has been a global leader in the design and manufacture of antennas and antenna systems for the military. Antenna Products works with military defense and governmental applications like the U.S. Army, Navy, Air Force, and Marine Corps. As a result, Antenna Products has become one of the top providers to the different branches of the U.S. Military and a proven partner with its exceptional line of products. With a legacy of innovation and an irreplaceable body of knowledge of RF performance and environmental requirements of militarized antenna systems, our robust lines of HF, VHF and UHF antennas have been designed specifically for superior performance under the most demanding conditions possible. Antenna Products has been proven to perform through thousands of mission critical deployments world-wide time and time again. Antenna Products has been working with and in conjunction with militaries for over 60 years to design, develop and manufacture mission critical antennas in support of troops worldwide.
HF Antennas
With one of the broadest product lines of HF antennas in the world, Antenna Products is the trusted manufacturer of mission-critical HF communications equipment for military, defense and governmental agencies everywhere.
Wideband Antennas
Antenna Products wideband antennas are specifically designed to perform over a wide frequency spectrum to minimize the amount of antennas required on a vehicle.
All Military Antennas
DPV-204 2025-2400 MHz Antenna
- Frequency Range: 2025-2400 MHz
- VSWR (max): 2.0:1 MHz (50 Ω)
- Gain: 7.5 dBi
- Polarization: Vertical
- Vertical -3dB Beamwidth: 12°(minimum)
- Horizontal -3dB Beamwidth: 360°
- Azimuth Ripple: +/-0.5 dB
- Power Input: 100 Watts (ave), 250 Watts (PEP)
DPV-203 2025-2400 MHz Antenna
- Frequency Range: 2025-2400 MHz
- VSWR (max): 2.0:1 MHz (50 Ω)
- Gain: 9 dBi (minimum)
- Polarization: Vertical
- Vertical -3dB Beamwidth: 7°(minimum)
- Horizontal -3dB Beamwidth: 360°
- Azimuth Ripple: +/-0.5 dB
- Power Input: 100 Watts (ave), 250 (PEP)
DPV-202 1755-1850 MHz Antenna
- Frequency Range: 1755-1850 MHz
- VSWR (max): 2.0:1 MHz (50 Ω)
- Gain: 7.5 dBi
- Polarization: Vertical
- Vertical -3dB Beamwidth: 12°(minimum)
- Horizontal -3dB Beamwidth: 360°
- Azimuth Ripple: +/-0.5 dB
- Power Input: 100 Watts (ave), 250 (PEP)
DPV-201 1300-1535 MHz Antenna
- Frequency Range: 1300-1535 MHz
- VSWR (max): 2.0:1 MHz (50 Ω)
- Gain: 7.5 dBi
- Polarization: Vertical
- Vertical -3dB Beamwidth: 12°(minimum)
- Horizontal -3dB Beamwidth: 360°
- Azimuth Ripple: +/-0.5 dB
- Power Input: 100 Watts (ave), 250 Watts (PEP)
DPV-200 1300-1535 MHz Antenna
- Frequency Range: 1300-1535 MHz
- VSWR (max): 2.0:1 MHz (50 Ω)
- Gain: 9 dBi (minimum)
- Polarization: Vertical
- Vertical -3dB Beamwidth: 7°(minimum)
- Horizontal -3dB Beamwidth: 360°
- Azimuth Ripple: +/-0.5 dB
- Power Input: 100 Watts (ave), 250 Watts (PEP)
MAGMOUNT X HEAVY DUTY MAGNETIC MOUNT
BCV-30512 30-512 MHz Bi-Conical Antenna
- Frequency Range: 30-512 MHz
- VSWR: 3.0:1 VSWR Typical
- Polarization: Vertical
- Maximum Power Input: 100 Watts*
- Size: 40 inches x 40 inches O.D. / < 15 lbs.
TLP-100.1 Log Periodic Antenna 100-1000MHz
- Frequency Range: 100-1000 MHz
- Gain: 6.5 dBi typical
- VSWR: 2.0:1 (typical) (50 Ω)
- Polarization: Linear
WB-1A Wideband Vehicular Antenna 200-6000MHz
- Frequency Range: 200-6000 MHz
- Gain: 2-6 dBi (frequency dependent)
- VSWR: ≤2.5:1
- Polarization: Vertical
- Pattern: 2-6 dBi (frequency dependent)
DPV-110A 2200-2400 MHz S-BAND ANTENNA
- Frequency Range: 2200-2400 MHz
- Gain: 10 dBi
- VSWR: 1.5:1 typ, 1.8:1 max (50 Ohm)
- Polarization: Vertical
- Size: 48” (1219.2 mm)
DPV-108A 1750-1850 MHz L-BAND ANTENNA
- Frequency Range: 1750-1850 MHz
- Gain: 10 dBi
- VSWR: 1.5:1 Max (50 Ohm)
- Polarization: Vertical
- Size: 52.23”(1327.15mm)
DPV-108 L-Band Antenna 1750-1850 MHz Omni-Directional Antenna
- Frequency Range: 1750-1850 MHz
- Gain: 10 +/- 0.3 dBi
- VSWR: 1.5:1 Max
- Polarization: Vertical
- Size: 48 inches x 1.5 inches O.D. ; 3 lbs.
